Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: SANYONTECH
  • Model Number: CD90
  • Size: 140*138*110mm
  • Precision: ±3mm/ 10m (±60°)
  • Wavelength: 650nm
  • Color: Red
  • Down dot accuracy: ±1mm/1.4m
  • Cross Accuracy: 90°±30''
  • Self-leveling range: approx.±2°
  • Power Supply: 4.8V-6V
  • Working Temperature: -10 -40℃
  • Cover: Plastic
  • Material: Plastic
  • Origin: China

Packaging & Delivery

Packaging Details 1PCS in 1Carton.Then will be packed in pallets.
Delivery Time 30Days

CD90 3D Multiline Laser Level cross line laser





·         Provides three precise 360-Degree full plane coverage in both horizontal and vertical operations

·         One horizontal and 2 vertical 360° lines enable many new applications for simultaneous marking, alignment and leveling indoors

·         Simple to use single button operation with little training requirements

·         90-Degree horizontal and vertical bright red laser layout lines and electronic self-leveling

·         Self-leveling (4° in 4 sec), very precise (± 0.2 mm/m) and range of up to 80 m with receiver

·         Compact, easy-to-handle and extremely robust (IP54)

·         Pulse and line selection mode options

·         No rotation or motors to wear-out or waste battery power

·         Smart pendulum leveling system self-levels and indicates out-of-level conditions

·         Pendulum Lock/Off: Protects pendulum during transportation and storage for added durability

·         Out-of-level and low power alarm warnings

·         Freestanding base with magnets to attach to metal track

·         Both 1/4 to 20-Inch and 5/8 to 11-Inch tripod mounting

·         Designed for all tradesmen, electricians, plumbers and carpenters



·         Interior decorating

·         Instrument installation

·         Floor and wall bricks

·         Drop ceiling

·         Wall frame

·         Level wall device

·         Wainscot

·         Level the cabinets and the shelves

·         Build the slope

·         And more...



·         Accuracy ±1mm/5m

·         Leveling Range ±3°

·         Working Range/With Detector 15m/60m with detector

·         Tripod Thread 1/4" & 5/8"

·         Laser Type 635 nm, laser class II

·         Operating Temperature -10 to 45

·         Storage Temperature -20 to 60

·         Dimension 166 x 88 x 126.5 mm

·         Continuous Working Time 5 hour(W/all Diodes on)

·         Protection Class Spray Water/Dust IP44

·         Net Weight 0.95kg
